Prosthetics

Upper extremity prosthetics

Prosthetic accessories

The active rotation feature is equipped with proportional control so the system is sensitive and functions exactly with the muscle signals. Proportional control is possible for both movements, rotation and the gripping function of the Michelangelo hand.

The battery charger is used to charge the AxonEnergy Integral (art. no. 757B501) of the Axon-Bus prosthesis solution. Charging proceeds automatically once the charging plug is connected to the charging receptacle of the AxonEnergy Integral.

The MyoCharge Integral is used to charge the MyoEnergy Integral integrated into the socket by simply connecting the charging plug to the charging receptacle on the outside of the socket. The integrated magnet and the special contour of the charging plug and charging receptacle ensure the quick and reliable positioning of both components.

The MyoEnergy Integral is an integrated power supply system for the MyoBock system. The charging receptacle indicates the current charge level using LEDs and allows the prosthesis to be switched on and off and opened in an emergency.

The PushValve is opened and closed by pressing together two wings. With its larger size, it is particularly suitable for users with limited finger mobility and for arm prosthesis wearers. The valve is compatible with all common liners without a distal connector and can also be used without a liner.This is a spare part for the 21Y14 PushValve.

A transhumeral soft harness for upper arm prostheses with myoelectric or passive elbow joints. The comfortable, padded harness consists of a sling and a sleeve and can be removed completely. Users can put it on and take it off with one hand.

The below-elbow harness is intended for fixation of the prosthetic socket and for control of body-powered prostheses. It is compatible with right and left-side prostheses.

The triple-control above-elbow harness is used to secure the prosthetic socket and control body-powered prostheses. It is compatible with right and left-side prostheses.

The Myo Plus TR control unit uses machine learning to measure and interpret existing muscle activity in the residual limb. As a result, movement patterns are recognised and assigned to prosthesis movements.

The MyolinoWrist 2000 mechanical ball wrist with adjustable friction for combination with the Electric Hand 2000 (article no. 8E51). Hand positioning in all directions reduces compensating movements. Additional degrees of freedom can support more natural movement patterns and a physiological body posture.

User group	adults, youths
Product family	Michelangelo Axon Bus
Product type	Electric Wrist Rotator

User group	youths, adults
Product family	Michelangelo Axon Bus
Product type	Battery charger, integrated

Product type	Battery charger, integrated
Product family	bebionic, Myobock prosthetic system for adults, Myobock prosthetic system for children, Dynamic Arm
User group	women, youths, men, adults, elderly

Product type	MyoEnergy Integrale
User group	women, youths, men, adults, elderly
Product family	Myobock prosthetic system for adults

Product type	Valves
Amputation level	Transfemoral amputation
Material	Plastic

Prosthetic accessories

AxonRotation

AxonCharge Integral

MyoCharge Integral

MyoEnergy Integral

PushValve

Transhumeral soft harness

Below-elbow harness

Triple-control above-elbow harness

Myo Plus TR

MyolinoWrist 2000

User group
Product family	Myobock prosthetic system for adults, Dynamic Arm
Colour	Grey

User group	children
Product family	Myobock prosthetic system for children
Product type	Mechanical wrist joint
